Horns/ Plastic Horns/ DKH-10RT seriesH-10T-15T-30T



DKH-10RT                                                                DKH-15RT

DKH-30RT



POWERFUL

The horn speakers DKH-10RT, DKH-15RT and DKH-30RT in light grey, are equipped with a rust-proof V4A-metal

bracket and also salt-water resistant screws with UV-resistant ABS plastic (similar to RAL 7035). The high protection standard IP66 and the high sound pressure level of the horn speakers are ideal for industrial applications and outdoor

use.

Besides the massive sound pressure levels you can also benefit from the flexible power adjustment  8 Ohm or 20 Ohm. The adjustment can easily be made on the back of the speaker. For our international customers we are

offering a 70 Volt tapping for the complete DKH-series.





Type

Power
(Watt)

Dimensions
(mm)

SPL P
max/1m (dB)

SPL
1W/1m (dB)

Frequency Range
(Hz)

Dispersion angle

DKH-10RT

10/5/2.5/1.25

137x200

112.4

102.4

400 - 10,000

360°

DKH-15RT

15/7.5/3.75/1.87

200x250

119.1

107.3

300 - 12,500

140°

DKH-30RT

30/20/10/5

237x287

124.9

110.1

300 - 6,000

130°
